Pioneer GM-DC871 Champion Series Class-D Mono Amplifier 1600w/500rms
1600W Max / 500W RMS at 2 ohms
Tuned to deliver deeper and louder bass
Champion Series Design
Variable LPF
RCA Input
Speaker Input
Perfect Match for TS-W312D4 Champion Series Subwoofer
Amplifier ClassClass D
No. of ChannelsMono
Max.power output800 W x 1 (4Ω) 1,600 W x 1 (2Ω)
RMS power output300 W x 1 (4Ω) 500 W x 1 (2Ω)
Frequency Response10 Hz to 240 Hz
Impedance1Ω to 8Ω
Total Harmonic Distortion(THD)<0.5% (100 Hz)
S/N Ratio100 dB
Speaker Level InputYes
Automatic Signal Sensing and Turn-OnYes
Crossover TypeVariable LPF
Crossover Frequency40 Hz to 240 Hz
Bass Boost Frequency56 Hz
Baas Boost Level0 dB to 18 dB
Bass Boost RemoteNo
Dimensions252 mm x 60 mm x 215 mm
